铁氧体牌号参数

Ganzhou Fortune Electronics Co., Ltd. Ferrite Magnets 铁氧体
NO.序号	GRADE牌号	Br (Gs)剩磁	Hcb (Oe)磁感矫顽力	Hcj (Oe)内禀矫顽力	(BH)max (MGOe)最大磁能积
1	FZ10T	2000 ~ 2350	1650 ~ 2000	2700 ~ 3300	0.8 ~ 1.1
2	FZ30	≥3800	2600 ± 150	2700 ± 150	≥3.3
3	FZ35/40	≥3400	3230 ± 150	4000 ± 150	2.75 ± 0.2
4	FZ30BH	≥3800	≥2750	≥2900	≥3.4
5	FZ30H-1	≥3800	≥2850	≥3000	≥3.45
6	FZ35	≥4000	2750 ± 150	2850 ± 150	≥3.8
7	FZ38/36	≥3750	3100 ± 150	3600 ± 150	≥3.2
8	FZ40/34	4000 ± 100	3300 ± 150	3400 ± 150	3.6 ± 0.2
9	FZ41/32	4100 ± 100	3100 ± 150	3200 ± 150	4.0 ± 0.2
10	FZ41/34	4100 ± 100	3150 ± 150	3350 ± 150	4.0 ± 0.2
11	FZ41/35	≥4000	≥3150	≥3300	≥3.8
12	FZ41/38	≥4000	≥3400	≥3600	≥4.0
13	FZ42/31	4150 ± 100	2950 ± 150	3100 ± 150	≥3.8
14	FZ42/32	≥4100	2900 ± 150	3100 ± 150	≥3.8
15	FZ40/36	4000 ± 100	3450 ± 150	3600 ± 150	3.8 ± 0.2
16	FZ40/38	4000 ± 100	3600 ± 150	3800 ± 150	3.8 ± 0.2
17	FZ39/39	3900 ± 100	3500 ± 150	3900 ± 150	3.6 ± 0.2
18	FZ40/40	4000 ± 100	3550 ± 150	4000 ± 150	4.0 ± 0.2
19	FZ41/40	4100 ± 100	3550 ± 150	4000 ± 150	4.1 ± 0.2
20	FZ41/41	4050 ± 100	3600 ± 150	4100 ± 150	4.1 ± 0.2
21	FZ41/46	≥4000	≥3800	≥4450	4.2 ± 0.2
22	FZ42/34	4150 ± 100	3200 ± 150	3300 ± 150	4.2 ± 0.2
23	FZ42/35	4200 ± 100	3250 ± 150	3400 ± 150	4.2 ± 0.2
24	FZ43/35	4250 ± 100	3250 ± 150	3400 ± 150	4.2 ± 0.2
25	FZ42/29	≥4100	≥2500	≥2700	3.8 ± 0.2
26	FZ42/40	4200 ± 100	3650 ± 150	3950 ± 150	4.2 ± 0.2
27	FZ42/41	4200 ± 100	3600 ± 150	4100 ± 150	4.2 ± 0.2
28	FZ42/43	4200 ± 100	3800 ± 150	4300 ± 150	4.2 ± 0.2
29	FZ42/46	≥4100	≥3800	≥4450	4.2 ± 0.2
30	FZ43/39	4200 ± 50	3700 ± 150	3850 ± 100	4.2 ± 0.2
31	FZ43/41	4250 ± 100	3700 ± 150	4050 ± 150	4.2 ± 0.2
32	FZ43/45	≥4200	≥3800	≥4350	4.4 ± 0.2
33	FZ43/46	≥4200	≥3850	≥4450	4.4 ± 0.2
34	FZ44/33	≥4300	≥3050	≥3150	4.4 ± 0.2
35	FZ44/34	≥4300	≥3100	≥3250	4.4 ± 0.2
36	FZ44/35	≥4300	≥3150	≥3300	4.4 ± 0.2
37	FZ44/45	≥4300	≥3800	≥4300	4.4 ± 0.2
38	FZ44/50	≥4300	≥3850	≥4750	4.4 ± 0.2
39	FZ45/36	≥4350	≥3350	≥3450	4.6 ± 0.2
40	FZ45/50	≥4350	≥4050	≥4850	4.8 ± 0.2
41	FZ46/36	≥4450	≥3350	≥3450	4.8 ± 0.2
42	FZ46/40	≥4450	≥3650	≥3850	5.1 ± 0.2
43	FZ46/45	≥4450	≥4100	≥4350	4.9 ± 0.2
44	FZ46/48	≥4450	≥4200	≥4650	5.0 ± 0.2
45	FZ46/50	≥4450	≥4200	≥4850	5.0 ± 0.2
